推土铲刀片_AutoCAD_模型图纸免费下载 – 探月网

推土铲刀片

5

0

0

平面图

免费下载

Tanyue675252

关注

创作: 36

粉丝: 1

加入时间：2025-07-12

模型信息

ID：2557

文件大小：3.53M

所需月贝：0

上传时间：2026-08-18 14:04:49

是否可编辑：可编辑含参数

版本：AutoCAD

标签

图纸简介

整体构成：推土铲 = 弧形主板 + 刀架 + 侧板 + 耳板；刀片（切削刃）是主板下沿通过犁头螺栓 / 高强度螺栓紧固的独立耐磨条，分可翻转双边刃、不可翻转单边刃、分段组合刃、刀角刃；标准直铲每侧常配 1 个刀角 + 多段中间刃，方便局部更换，降低成本。安装面：铲刃与主板接触面常为平面 / 斜面，带定位销防窜动；螺栓按等距排布（常见 1200mm 刃条配 8–10 组螺栓）。高度差：刃口低于主板约 10–15mm，磨损后翻转或更换，保护昂贵的铲刀本体。

版权说明

会员在本站下载的原创作品，只拥有作品的使用权，著作权归原作者所有，未经合法授权，会员不得以任何形式发布、传播、复制、转售该作品。
